5-6605727-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 5-6605727-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 1 Port RJ45 Magjack Connector Through Hole 10/100 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 5-6605727-1 Price |  |
Technical Specifications of 5-6605727-1
| Category | Connectors, Interconnects |
|---|---|
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | TE-Connectivity-AMP-Connectors |
| Series | Mag45 |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.555" (14.10mm) |
| LED Color | Green - Yellow |
| Number of Cores per Jack | 6 |
| Shielding | Shielded, EMI Finger |
| Features | Board Lock, Decoupling Capacitance |
| Tab Direction | Up |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 50μin (1.27μm) |
| Shield Material | Brass |
| Housing Material | Polyethylene Terephthalate (PET), Polyester |
| Operating Temperature | 0°C ~ 70°C |
