7498111120R
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 7498111120R |
|---|---|
| Manufacturer | Wurth Electronics Inc |
| Description | 1 Port RJ45 Magjack Connector Board Edge, Cutout; Surface Mount 10/100/1000 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 7498111120R Price |  |
Technical Specifications of 7498111120R
| Datasheet |  7498111120R datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Wurth-Electronics-Inc |
| Series | WE-RJ45 |
| Packaging | Tape & Reel (TR) |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Board Edge, Cutout; Surface Mount |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.350" (8.89mm) |
| LED Color | Yellow - Green |
| Number of Cores per Jack | 8 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide, Solder Retention |
| Tab Direction | Up |
| Contact Material | Tin |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Copper Alloy |
| Housing Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
