ARJ21A-MCSD-MU2
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ARJ21A-MCSD-MU2 |
|---|---|
| Manufacturer | Abracon LLC |
| Description | 2 Port RJ45 Magjack Connector Through Hole 10/100/1000 Base-TX, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ARJ21A-MCSD-MU2 Price |  |
Technical Specifications of ARJ21A-MCSD-MU2
| Datasheet |  ARJ21A-MCSD-MU2 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Abracon-LLC |
| Series | ARJ21A |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 2 |
| Number of Rows | 2 |
| Applications | 10/100/1000 Base-TX, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.996" (25.30mm) |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, EMI Finger |
| Features | Board Lock |
| Tab Direction | Up and Down |
| Contact Material | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 6μin (0.152μm) |
| Shield Material | - |
| Housing Material | - |
| Operating Temperature | 0°C ~ 70°C |
