TIC-L005-14
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TIC-L005-14 |
|---|---|
| Manufacturer | Tamura |
| Description | 4 Port RJ45 Magjack Connector Through Hole 10/100 Base-TX, AutoMDIX |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| TIC-L005-14 Price |  |
Technical Specifications of TIC-L005-14
| Category | Connectors, Interconnects |
|---|---|
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Tamura |
| Series | TIC |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 4 |
| Number of Rows | 1 |
| Applications | 10/100 Base-TX, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.530" (13.45mm) |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, EMI Finger |
| Features | Board Lock |
| Tab Direction | Down |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Stainless Steel |
| Housing Material | Polyamide (PA6T), Nylon 6T |
| Operating Temperature | 0°C ~ 85°C |
