JC0-3022NL
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | JC0-3022NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | 12 Port RJ45 Magjack Connector Through Hole 10/100/1000 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| JC0-3022NL Price |  |
Technical Specifications of JC0-3022NL
| Datasheet |  JC0-3022NL datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Pulse-Electronics-Corporation |
| Series | PULSEJACK? JC0 |
| Packaging | Bulk |
| Connector Type | RJ45 |
| Number of Ports | 12 |
| Number of Rows | 2 |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.995" (25.28mm) |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 8 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide |
| Tab Direction | Up and Down |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Copper Alloy |
| Housing Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
