J1N-0007NL
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | J1N-0007NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | 4 Port RJ45 Magjack Connector Through Hole 10/100/1000 Base-T, Power over Ethernet (PoE) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| J1N-0007NL Price |  |
Technical Specifications of J1N-0007NL
| Datasheet |  J1N-0007NL datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Pulse-Electronics-Corporation |
| Series | PULSEJACK? J1N |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 4 |
| Number of Rows | 1 |
| Applications | 10/100/1000 Base-T, Power over Ethernet (PoE) |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.480" (12.19mm) |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 9 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide |
| Tab Direction | Up |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Brass |
| Housing Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
