08B0-1D1T-03-F
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 08B0-1D1T-03-F |
|---|---|
| Manufacturer | Bel Fuse Inc. |
| Description | 1 Port RJ45 Magjack Connector Through Hole 10/100 Base-T |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 08B0-1D1T-03-F Price |  |
Technical Specifications of 08B0-1D1T-03-F
| Datasheet |  08B0-1D1T-03-F datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Bel-Fuse-Inc. |
| Series | MagJack? |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100 Base-T |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.531" (13.50mm) |
| LED Color | Yellow - Green |
| Number of Cores per Jack | 5 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide |
| Tab Direction | Up |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | 15μin (0.38μm) |
| Shield Material | Copper Alloy |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Operating Temperature | 0°C ~ 70°C |
