J0026D01ENL
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | J0026D01ENL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | 1 Port RJ45 Magjack Connector Through Hole 10/100 Base-TX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| J0026D01ENL Price |  |
Technical Specifications of J0026D01ENL
| Datasheet |  J0026D01ENL datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Pulse-Electronics-Corporation |
| Series | PULSEJACK? J0 |
| Packaging | Bulk |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100 Base-TX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.545" (13.84mm) |
| LED Color | Green - Green |
| Number of Cores per Jack | 5 |
| Shielding | Shielded |
| Features | Board Guide |
| Tab Direction | Down |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 15μin (0.38μm) |
| Shield Material | Brass |
| Housing Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
