FN286B-1-06
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FN286B-1-06 |
|---|---|
| Manufacturer | Schaffner EMC Inc. |
| Description | PWR ENT MOD RCPT IEC320-C14 PNL |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FN286B-1-06 Price |  |
Technical Specifications of FN286B-1-06
| Datasheet |  FN286B-1-06 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Power Entry Connectors - Inlets, Outlets, Modules |
| Manufacturer | Schaffner-EMC-Inc. |
| Series | FN 280 |
| Packaging | Bulk |
| Connector Style | IEC 320-C14 |
| Connector Type | Receptacle, Male Blades - Module |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 1A |
| Voltage - UL | 250VAC |
| Filter Type | Filtered (EMI, RFI) - Commercial, Medical |
| Fuse | Yes |
| Number of Positions | 3 |
| Mounting Type | Panel Mount, Snap-In |
| Termination | Quick Connect - 0.250" (6.3mm) |
| Switch Features | Switch On-Off |
| Features | Bleed Resistor |
| Fuse Holder, Drawer | Fuse Holder, Twin Fused |
| Panel Cutout Dimensions | Rectangular - 29.00mm x 61.50mm |
| Panel Thickness | 0.031" ~ 0.118" (0.79mm ~ 3.00mm) |
| Material Flammability Rating | UL94 V-2 |
| Ingress Protection | IP40 |
| Approvals | CQC, CSA, ENEC, UL |
