ZW-16-13-L-S-730-090
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ZW-16-13-L-S-730-090 |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN BOARD STKR HDR 16POS 2.54MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ZW-16-13-L-S-730-090 Price |  |
Technical Specifications of ZW-16-13-L-S-730-090
| Datasheet |  ZW-16-13-L-S-730-090 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Samtec-Inc. |
| Series | Flex Stack, ZW |
| Packaging | Tube |
| Number of Positions | 16 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Length - Overall | 1.230" (31.24mm) |
| Length - Post (Mating) | 0.410" (10.41mm) |
| Length - Stack Height | 0.730" (18.54mm) |
| Length - Tail | 0.090" (2.29mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 10μin (0.25μm) |
| Color | Black |
