FW-20-04-G-D-380-125
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FW-20-04-G-D-380-125 |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN BOARD STKR HDR .50" 40POS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FW-20-04-G-D-380-125 Price |  |
Technical Specifications of FW-20-04-G-D-380-125
| Datasheet |  FW-20-04-G-D-380-125 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Samtec-Inc. |
| Series | Flex Stack, FW |
| Packaging | Tube |
| Number of Positions | 40 |
| Pitch | 0.050" (1.27mm) |
| Number of Rows | 2 |
| Row Spacing | 0.050" (1.27mm) |
| Length - Overall | 0.595" (15.11mm) |
| Length - Post (Mating) | 0.126" (3.20mm) |
| Length - Stack Height | 0.380" (9.65mm) |
| Length - Tail | 0.090" (2.29mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 10μin (0.25μm) |
| Color | Black |
