961426-8041604-AR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 961426-8041604-AR |
|---|---|
| Manufacturer | 3M |
| Description | HEADER 26POS STR DUAL INSUL 2ROW |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 961426-8041604-AR Price |  |
Technical Specifications of 961426-8041604-AR
| Datasheet |  961426-8041604-AR datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | 3M |
| Series | 961 |
| Packaging | Bulk |
| Number of Positions | 26 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Length - Overall | 1.638" (41.60mm) |
| Length - Post (Mating) | 0.256" (6.50mm) |
| Length - Stack Height | 1.252" (31.80mm) |
| Length - Tail | 0.130" (3.30mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | Flash |
| Color | Black |
