TW-10-07-G-D-500-SM-P
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TW-10-07-G-D-500-SM-P |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN HEADER DUAL 2MM 20POS GOLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TW-10-07-G-D-500-SM-P Price |  |
Technical Specifications of TW-10-07-G-D-500-SM-P
| Datasheet |  TW-10-07-G-D-500-SM-P datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Samtec-Inc. |
| Series | Flex Stack; TW |
| Packaging | Tube |
| Number of Positions | 20 |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 2 |
| Row Spacing | 0.079" (2.00mm) |
| Length - Overall | 0.683" (17.35mm) |
| Length - Post (Mating) | 0.183" (4.65mm) |
| Length - Stack Height | 0.500" (12.70mm) |
| Length - Tail | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 20μin (0.51μm) |
| Color | Black |
