M22-2671546
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | M22-2671546 |
|---|---|
| Manufacturer | Harwin Inc. |
| Description | 15 SIL EXT P/HDR 12MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| M22-2671546 Price |  |
Technical Specifications of M22-2671546
| Category | Connectors, Interconnects |
|---|---|
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Harwin-Inc. |
| Series | M22 |
| Packaging | Bulk |
| Number of Positions | 15 |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Length - Overall | 0.705" (17.91mm) |
| Length - Post (Mating) | 0.138" (3.50mm) |
| Length - Stack Height | 0.472" (12.00mm) |
| Length - Tail | 0.095" (2.41mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Tin |
| Contact Finish Thickness - Post (Mating) | - |
| Color | Black |
