ZW-12-10-S-D-400-100
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ZW-12-10-S-D-400-100 |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN BOARD STKR HDR 24POS 2.54MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ZW-12-10-S-D-400-100 Price |  |
Technical Specifications of ZW-12-10-S-D-400-100
| Datasheet |  ZW-12-10-S-D-400-100 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Samtec-Inc. |
| Series | Flex Stack, ZW |
| Packaging | Tube |
| Number of Positions | 24 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Length - Overall | 0.830" (21.08mm) |
| Length - Post (Mating) | 0.330" (8.38mm) |
| Length - Stack Height | 0.400" (10.16mm) |
| Length - Tail | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 30μin (0.76μm) |
| Color | Black |
