FW-20-05-L-D-476-065
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FW-20-05-L-D-476-065 |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN HDR 40 POS 1.27MM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FW-20-05-L-D-476-065 Price |  |
Technical Specifications of FW-20-05-L-D-476-065
| Datasheet |  FW-20-05-L-D-476-065 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Samtec-Inc. |
| Series | Flex Stack, FW |
| Packaging | Tube |
| Number of Positions | 40 |
| Pitch | 0.050" (1.27mm) |
| Number of Rows | 2 |
| Row Spacing | 0.050" (1.27mm) |
| Length - Overall | 0.541" (13.74mm) |
| Length - Post (Mating) | 0.065" (1.65mm) |
| Length - Stack Height | 0.476" (12.09mm) |
| Length - Tail | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 10μin (0.25μm) |
| Color | Black |
