149009-4
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 149009-4 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CONN PLUG VERT 100POS 30GOLD PCB |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 149009-4 Price |  |
Technical Specifications of 149009-4
| Datasheet |  149009-4 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Manufacturer | TE-Connectivity-AMP-Connectors |
| Series | Micro-Strip |
| Packaging | Tray |
| Connector Type | Shrouded |
| Number of Positions | 100 |
| Number of Positions Loaded | All |
| Pitch | 0.050" (1.27mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Height Stacking (Mating) | 0.738" (18.75mm) |
| Molding Height Above Board | 0.648" (16.46mm) |
| Contact Mating Length | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Features | Ground Bus (Plane) |
| Color | Natural |
