Include WithHome > Products > Connectors, Interconnects > Rectangular - Board to Board Connectors - Headers, Male Pins > 0532290209
0532290209
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0532290209 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | CONN HDR 20POS T/H 2.54MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0532290209 Price |  |
Technical Specifications of 0532290209
| Datasheet |  0532290209 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Manufacturer | Molex,-LLC |
| Series | 53229 |
| Packaging | Bulk |
| Connector Type | Shrouded |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Height Stacking (Mating) | - |
| Molding Height Above Board | 0.453" (11.50mm) |
| Contact Mating Length | 0.193" (4.90mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish | - |
| Contact Finish Thickness | - |
| Features | Mounting Flange |
| Color | White |
