73547-115LF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 73547-115LF |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | CONN HEADER 30POS .050" STR PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 73547-115LF Price |  |
Technical Specifications of 73547-115LF
| Datasheet |  73547-115LF datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Manufacturer | Amphenol-FCI |
| Series | Rib-Cage?, MezzSelect? |
| Packaging | Tube |
| Connector Type | Shrouded |
| Number of Positions | 30 |
| Number of Positions Loaded | All |
| Pitch | 0.050" (1.27mm) |
| Number of Rows | 2 |
| Row Spacing | 0.050" (1.27mm) |
| Height Stacking (Mating) | 0.391" (9.93mm) |
| Molding Height Above Board | 0.364" (9.25mm) |
| Contact Mating Length | 0.130" (3.30mm) |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Finish | Gold or Gold, GXT? |
| Contact Finish Thickness | 30μin (0.76μm) |
| Features | Board Guide |
| Color | Natural |
