1-534974-3
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1-534974-3 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 42 Position Receptacle Connector Gold 0.100" (2.54mm) Through Hole, Right Angle |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 1-534974-3 Price |  |
Technical Specifications of 1-534974-3
| Datasheet |  1-534974-3 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | TE-Connectivity-AMP-Connectors |
| Series | AMPMODU Mod II |
| Packaging | Tube |
| Connector Type | Receptacle |
| Number of Positions | 42 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 3 |
| Row Spacing | 0.100" (2.54mm) |
| Height Stacking (Mating) | - |
| Height Above Board | 0.338" (8.58mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Features | - |
| Color | - |
