HLE-105-02-G-DV-P
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HLE-105-02-G-DV-P |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | 10 Position Receptacle Connector Gold 0.100" (2.54mm) Surface Mount |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HLE-105-02-G-DV-P Price |  |
Technical Specifications of HLE-105-02-G-DV-P
| Datasheet |  HLE-105-02-G-DV-P datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | Samtec-Inc. |
| Series | HLE |
| Packaging | Tube |
| Connector Type | Receptacle |
| Number of Positions | 10 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Height Stacking (Mating) | - |
| Height Above Board | 0.144" (3.66mm) |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Finish | Gold |
| Contact Finish Thickness | 20μin (0.51μm) |
| Features | - |
| Color | Black |
