71609-304LF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 71609-304LF |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | 8 Position Receptacle Connector Gold 0.100" (2.54mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 71609-304LF Price |  |
Technical Specifications of 71609-304LF
| Datasheet |  71609-304LF datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | Amphenol-FCI |
| Series | DUBOX?, MezzSelect?, Basics+ |
| Packaging | Tube |
| Connector Type | Receptacle |
| Number of Positions | 8 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Height Stacking (Mating) | - |
| Height Above Board | 0.230" (5.85mm) |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Features | - |
| Color | Gray |
