AWP20-7540-T-R
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AWP20-7540-T-R |
|---|---|
| Manufacturer | Assmann WSW Components |
| Description | CONN SOCKET IDC 20POS W/KEY TIN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| AWP20-7540-T-R Price |  |
Technical Specifications of AWP20-7540-T-R
| Datasheet |  AWP20-7540-T-R datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Free Hanging, Panel Mount |
| Manufacturer | Assmann-WSW-Components |
| Series | - |
| Packaging | Tray |
| Connector Type | Socket |
| Contact Type | Female Socket |
| Number of Positions | 20 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Mounting Type | Free Hanging (In-Line) |
| Fastening Type | - |
| Cable Termination | IDC |
| Wire Type | Ribbon Cable |
| Wire Gauge | - |
| Features | Feed Through, Polarizing Key |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Gray |
