DF14A-20P-1.25H(56)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DF14A-20P-1.25H(56) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 20 Positions Header, Shrouded Connector 0.049" (1.25mm) Surface Mount, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DF14A-20P-1.25H(56) Price |  |
Technical Specifications of DF14A-20P-1.25H(56)
| Datasheet |  DF14A-20P-1.25H(56) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Hirose-Electric-Co-Ltd |
| Series | DF14 |
| Packaging | Tape & Reel (TR) |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.049" (1.25mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | - |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Color | Beige |
