A1-16PA-2.54DS(74)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | A1-16PA-2.54DS(74) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 16 Positions Header, Unshrouded Connector 0.100" (2.54mm) Through Hole, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| A1-16PA-2.54DS(74) Price |  |
Technical Specifications of A1-16PA-2.54DS(74)
| Datasheet |  A1-16PA-2.54DS(74) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Hirose Electric Co Ltd |
| Series | A1 |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded |
| Number of Positions | 16 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Contact Mating Length | 0.236" (6.00mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 8μin (0.20μm) |
| Color | Black |
