S05B-PASK-2
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | S05B-PASK-2 |
|---|---|
| Manufacturer | JST Sales America Inc. |
| Description | 5 Positions Header, Shrouded Connector 0.079" (2.00mm) Through Hole, Right Angle Tin-Lead |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| S05B-PASK-2 Price |  |
Technical Specifications of S05B-PASK-2
| Category | Connectors, Interconnects |
|---|---|
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JST Sales America Inc. |
| Series | PA |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 5 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.126" (3.20mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Kinked Pin, Solder |
| Fastening Type | Locking Ramp |
| Features | Board Guide |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | - |
| Color | Natural |
