IL-AG5-22P-D3T2
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | IL-AG5-22P-D3T2 |
|---|---|
| Manufacturer | JAE Electronics |
| Description | 22 Positions Header, Shrouded Connector 0.098" (2.50mm) Through Hole Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| IL-AG5-22P-D3T2 Price |  |
Technical Specifications of IL-AG5-22P-D3T2
| Datasheet |  IL-AG5-22P-D3T2 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JAE Electronics |
| Series | IL-AG5 |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 22 |
| Number of Positions Loaded | All |
| Pitch | 0.098" (2.50mm) |
| Number of Rows | 2 |
| Row Spacing | 0.118" (3.00mm) |
| Contact Mating Length | 0.331" (8.40mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Green |
