7-292206-0
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 7-292206-0 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 20 Positions Header, Shrouded Connector 0.059" (1.50mm) Through Hole, Right Angle Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 7-292206-0 Price |  |
Technical Specifications of 7-292206-0
| Datasheet |  7-292206-0 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | Mini CT |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.059" (1.50mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.094" (2.40mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Blue |
