S8B-PH-SM3-TB
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | S8B-PH-SM3-TB |
|---|---|
| Manufacturer | JST Sales America Inc. |
| Description | 8 Positions Header, Shrouded Connector 0.079" (2.00mm) Surface Mount, Right Angle Tin-Lead |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| S8B-PH-SM3-TB Price |  |
Technical Specifications of S8B-PH-SM3-TB
| Category | Connectors, Interconnects |
|---|---|
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JST Sales America Inc. |
| Series | PH |
| Packaging | Tape & Reel (TR) |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 8 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.130" (3.30mm) |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | Detent Lock |
| Features | Solder Retention |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | - |
| Color | Natural |
