SM05B-SRSS-TB(LF)(SN)
(SN).jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SM05B-SRSS-TB(LF)(SN) |
|---|---|
| Manufacturer | JST Sales America Inc. |
| Description | 5 Positions Header, Shrouded Connector 0.039" (1.00mm) Surface Mount, Right Angle Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SM05B-SRSS-TB(LF)(SN) Price |  |
Technical Specifications of SM05B-SRSS-TB(LF)(SN)
| Datasheet |  SM05B-SRSS-TB(LF)(SN) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JST Sales America Inc. |
| Series | SR |
| Packaging | Tape & Reel (TR) |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 5 |
| Number of Positions Loaded | All |
| Pitch | 0.039" (1.00mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | - |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | Solder Retention |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Natural |
