MMT-109-01-S-DH
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MMT-109-01-S-DH |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | 18 Positions Header, Unshrouded Connector 0.079" (2.00mm) Surface Mount, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MMT-109-01-S-DH Price |  |
Technical Specifications of MMT-109-01-S-DH
| Datasheet |  MMT-109-01-S-DH datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Samtec Inc. |
| Series | MMT |
| Packaging | Tube |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded |
| Number of Positions | 18 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 2 |
| Row Spacing | 0.079" (2.00mm) |
| Contact Mating Length | 0.126" (3.20mm) |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Color | Black |
