HIF4-26P-3.18DSA(01)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HIF4-26P-3.18DSA(01) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 26 Positions Header, Shrouded Connector 0.125" (3.18mm) Through Hole Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HIF4-26P-3.18DSA(01) Price |  |
Technical Specifications of HIF4-26P-3.18DSA(01)
| Category | Connectors, Interconnects |
|---|---|
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Hirose Electric Co Ltd |
| Series | HIF4 |
| Packaging | Tray |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 26 |
| Number of Positions Loaded | All |
| Pitch | 0.125" (3.18mm) |
| Number of Rows | 2 |
| Row Spacing | 0.125" (3.18mm) |
| Contact Mating Length | 0.201" (5.10mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Latch Lock/Eject Hooks |
| Features | Mounting Flange |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Color | Black |
