961128-5500-AR-TP
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 961128-5500-AR-TP |
|---|---|
| Manufacturer | 3M |
| Description | 28 Positions Header, Unshrouded Connector 0.100" (2.54mm) Surface Mount, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 961128-5500-AR-TP Price |  |
Technical Specifications of 961128-5500-AR-TP
| Datasheet |  961128-5500-AR-TP datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | 3M |
| Series | 961 |
| Packaging | Tube |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded |
| Number of Positions | 28 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.230" (5.84mm) |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Color | Black |
