0015271501
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | 0015271501 |
---|---|
Manufacturer | Molex, LLC |
Description | 5 Positions Header, Shrouded Connector 0.165" (4.20mm) Through Hole, Right Angle Gold |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
0015271501 Price |
Technical Specifications of 0015271501
Datasheet | 0015271501 datasheet |
---|---|
Category | Connectors, Interconnects |
Family | Rectangular Connectors - Headers, Male Pins |
Manufacturer | Molex,-LLC |
Series | Mini-Fit? Jr? 5569 |
Packaging | Bulk |
Contact Type | Male Pin |
Connector Type | Header, Shrouded |
Number of Positions | 5 |
Number of Positions Loaded | All |
Pitch | 0.165" (4.20mm) |
Number of Rows | 1 |
Row Spacing | - |
Contact Mating Length | - |
Mounting Type | Through Hole, Right Angle |
Termination | Solder |
Fastening Type | Locking Ramp |
Features | Board Lock |
Contact Finish | Gold |
Contact Finish Thickness | 15μin (0.38μm) |
Color | Natural |
