22-12-2114
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 22-12-2114 |
|---|---|
| Manufacturer | Molex Connector Corporation |
| Description | 11 Positions Header, Unshrouded Connector 0.100" (2.54mm) Through Hole, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 22-12-2114 Price |  |
Technical Specifications of 22-12-2114
| Datasheet |  22-12-2114 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Molex Connector Corporation |
| Series | KK? 7478 |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded |
| Number of Positions | 11 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.264" (6.70mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | Friction Lock |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 20μin (0.51μm) |
| Color | White |
