SMH101-LPSE-D15-SP-BK
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SMH101-LPSE-D15-SP-BK |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | 30 Positions Header, Unshrouded Connector 0.039" (1.00mm) Surface Mount Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SMH101-LPSE-D15-SP-BK Price |  |
Technical Specifications of SMH101-LPSE-D15-SP-BK
| Category | Connectors, Interconnects |
|---|---|
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Sullins Connector Solutions |
| Series | SMH |
| Packaging | Tube |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded |
| Number of Positions | 30 |
| Number of Positions Loaded | All |
| Pitch | 0.039" (1.00mm) |
| Number of Rows | 2 |
| Row Spacing | 0.039" (1.00mm) |
| Contact Mating Length | 0.065" (1.65mm) |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | - |
| Features | Board Guide |
| Contact Finish | Gold |
| Contact Finish Thickness | 10μin (0.25μm) |
| Color | Black |
