1-535676-3
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1-535676-3 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 14 Position Receptacle Connector 0.100" (2.54mm) Through Hole, Right Angle Gold |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 1-535676-3 Price |  |
Technical Specifications of 1-535676-3
| Datasheet |  1-535676-3 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | AMPMODU Mod II |
| Packaging | Tube |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 14 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Color | Black |
