09-48-4109
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 09-48-4109 |
|---|---|
| Manufacturer | Molex Connector Corporation |
| Description | 10 Position Receptacle, Bottom Entry Connector 0.156" (3.96mm) Through Hole Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 09-48-4109 Price |  |
Technical Specifications of 09-48-4109
| Datasheet |  09-48-4109 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | Molex Connector Corporation |
| Series | KK? 41815 |
| Packaging | Tray |
| Connector Type | Receptacle, Bottom Entry |
| Contact Type | Female Socket |
| Number of Positions | 10 |
| Number of Positions Loaded | All |
| Pitch | 0.156" (3.96mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Locking Ramp |
| Features | - |
| Contact Finish | Tin |
| Contact Finish Thickness | 200μin (5.08μm) |
| Color | Natural |
