FI-X20S-HF-NPB
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FI-X20S-HF-NPB |
|---|---|
| Manufacturer | JAE Electronics |
| Description | 20 Position Receptacle Connector 0.039" (1.00mm) Surface Mount, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FI-X20S-HF-NPB Price |  |
Technical Specifications of FI-X20S-HF-NPB
| Datasheet |  FI-X20S-HF-NPB datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | JAE Electronics |
| Series | FI-X |
| Packaging | Tray |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.039" (1.00mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | Solder Retention |
| Contact Finish | Gold |
| Contact Finish Thickness | 3.9μin (0.10μm) |
| Color | Beige |
