LCQT-SOIC32W
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | LCQT-SOIC32W |
|---|---|
| Manufacturer | Aries Electronics |
| Description | IC Socket Adapter SOIC-W To DIP, 0.6" (15.24mm) Row Spacing Through Hole |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| LCQT-SOIC32W Price |  |
Technical Specifications of LCQT-SOIC32W
| Datasheet |  LCQT-SOIC32W datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Sockets for ICs, Transistors - Adapters |
| Manufacturer | Aries Electronics |
| Series | Correct-A-Chip? |
| Convert From (Adapter End) | SOIC-W |
| Convert To (Adapter End) | DIP, 0.6" (15.24mm) Row Spacing |
| Number of Pins | 32 |
| Pitch - Mating | 0.050" (1.27mm) |
| Contact Finish - Mating | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Pitch - Post | 0.100" (2.54mm) |
| Contact Finish - Post | Gold |
| Housing Material | Polyester |
| Board Material | FR4 Epoxy Glass |
| Termination Post Length | 0.236" (6.00mm) |
| Material Flammability Rating | UL94 V-0 |
| Features | - |
| Current Rating | - |
| Operating Temperature | -55°C ~ 125°C |
| Contact Material - Mating | - |
| Contact Material - Post | Brass |
| Contact Finish Thickness - Mating | - |
| Contact Finish Thickness - Post | Flash |
