MPP-1100-05-DS-4GR(S1402)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MPP-1100-05-DS-4GR(S1402) |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | CONN TRANSIST TO-220/TO-247 5POS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MPP-1100-05-DS-4GR(S1402) Price |  |
Technical Specifications of MPP-1100-05-DS-4GR(S1402)
| Datasheet |  MPP-1100-05-DS-4GR(S1402) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Sockets for ICs, Transistors |
| Manufacturer | Sullins Connector Solutions |
| Series | - |
| Packaging | Bulk |
| Type | Transistor, TO-220 and TO-247 |
| Number of Positions or Pins (Grid) | 5 (Rectangular) |
| Pitch - Mating | - |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 30μin (0.76μm) |
| Contact Material - Mating | Nickel Boron |
| Mounting Type | Through Hole, Right Angle |
| Features | - |
| Termination | Solder |
| Pitch - Post | - |
| Contact Finish - Post | Gold |
| Contact Finish Thickness - Post | 30μin (0.76μm) |
| Contact Material - Post | Nickel Boron |
| Housing Material | Polyphenylene Sulfide (PPS) |
| Operating Temperature | -65°C ~ 200°C |
| Termination Post Length | 0.125" (3.18mm) |
| Material Flammability Rating | - |
| Current Rating | 3A |
| Contact Resistance | 30 mOhm |
