Technical Specifications of 08-6823-90C
| Datasheet |  08-6823-90C datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Sockets for ICs, Transistors |
|---|
| Manufacturer | Aries Electronics |
|---|
| Series | Vertisockets? 800 |
|---|
| Packaging | Bulk |
|---|
| Type | DIP, 0.6" (15.24mm) Row Spacing |
|---|
| Number of Positions or Pins (Grid) | 8 (2 x 4) |
|---|
| Pitch - Mating | 0.100" (2.54mm) |
|---|
| Contact Finish - Mating | Gold |
|---|
| Contact Finish Thickness - Mating | 30μin (0.76μm) |
|---|
| Contact Material - Mating | Beryllium Copper |
|---|
| Mounting Type | Through Hole, Right Angle, Horizontal |
|---|
| Features | Closed Frame |
|---|
| Termination | Solder |
|---|
| Pitch - Post | 0.100" (2.54mm) |
|---|
| Contact Finish - Post | Tin |
|---|
| Contact Finish Thickness - Post | 200μin (5.08μm) |
|---|
| Contact Material - Post | Brass |
|---|
| Housing Material | Polyamide (PA46), Nylon 4/6, Glass Filled |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Termination Post Length | 0.140" (3.56mm) |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 3A |
|---|
| Contact Resistance | - |
|---|
We can supply Aries Electronics part# 08-6823-90C. Use the request quote form to request 08-6823-90C pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 08-6823-90C. The price and lead time for 08-6823-90C depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 08-6823-90C. We look forward to doing business with you.
