Technical Specifications of 241-20-1-03
| Datasheet |  241-20-1-03 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Sockets for ICs, Transistors |
|---|
| Manufacturer | CNC Tech |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| Type | DIP, 0.3" (7.62mm) Row Spacing |
|---|
| Number of Positions or Pins (Grid) | 20 (2 x 10) |
|---|
| Pitch - Mating | 0.100" (2.54mm) |
|---|
| Contact Finish - Mating | Tin |
|---|
| Contact Finish Thickness - Mating | 60μin (1.52μm) |
|---|
| Contact Material - Mating | Phosphor Bronze |
|---|
| Mounting Type | Through Hole |
|---|
| Features | Open Frame |
|---|
| Termination | Solder |
|---|
| Pitch - Post | 0.100" (2.54mm) |
|---|
| Contact Finish - Post | Tin |
|---|
| Contact Finish Thickness - Post | 60μin (1.52μm) |
|---|
| Contact Material - Post | Phosphor Bronze |
|---|
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
|---|
| Operating Temperature | -40°C ~ 105°C |
|---|
| Termination Post Length | 0.124" (3.15mm) |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 1A |
|---|
| Contact Resistance | 20 mOhm |
|---|
We can supply CNC Tech part# 241-20-1-03. Use the request quote form to request 241-20-1-03 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 241-20-1-03. The price and lead time for 241-20-1-03 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 241-20-1-03. We look forward to doing business with you.
