Technical Specifications of 3-796602-8
| Datasheet |  3-796602-8 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminal Blocks - Barrier Blocks |
|---|
| Manufacturer | TE Connectivity AMP Connectors |
|---|
| Series | SSB7, Buchanan |
|---|
| Packaging | Bulk |
|---|
| Terminal Block Type | Barrier Block |
|---|
| Number of Circuits | 4 |
|---|
| Number of Wire Entries | 4 |
|---|
| Pitch | 0.438" (11.12mm) |
|---|
| Number of Rows | 1 |
|---|
| Current Rating | 20A |
|---|
| Voltage Rating | 600V |
|---|
| Wire Gauge | 12-22 AWG |
|---|
| Top Termination | Screws with Captive Plate |
|---|
| Bottom Termination | Quick Connect (0.250"), Insulated |
|---|
| Barrier Type | 2 Wall (Dual) |
|---|
| Features | Flange |
|---|
| Color | Black |
|---|
| Terminal Screw Material | Steel |
|---|
| Terminal Screw Finish | Zinc, Clear Chromate |
|---|
| Mounting Type | Chassis, Panel |
|---|
| Operating Temperature | -60°C ~ 105°C |
|---|
| Material - Insulation | Thermoplastic |
|---|
| Material Flammability Rating | UL94 V-2 |
|---|
We can supply TE Connectivity AMP Connectors part# 3-796602-8. Use the request quote form to request 3-796602-8 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 3-796602-8. The price and lead time for 3-796602-8 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 3-796602-8. We look forward to doing business with you.
