Technical Specifications of TB100-09
| Datasheet |  TB100-09 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminal Blocks - Barrier Blocks |
|---|
| Manufacturer | Eaton |
|---|
| Series | Magnum? TB100 |
|---|
| Packaging | Bulk |
|---|
| Terminal Block Type | Barrier Block |
|---|
| Number of Circuits | 9 |
|---|
| Number of Wire Entries | 18 |
|---|
| Pitch | 0.375" (9.53mm) |
|---|
| Number of Rows | 2 |
|---|
| Current Rating | 20A |
|---|
| Voltage Rating | 300V |
|---|
| Wire Gauge | 14-22 AWG |
|---|
| Top Termination | Screws |
|---|
| Bottom Termination | Closed |
|---|
| Barrier Type | 2 Wall (Dual) |
|---|
| Features | Flange |
|---|
| Color | Black |
|---|
| Terminal Screw Material | Steel |
|---|
| Terminal Screw Finish | Zinc |
|---|
| Mounting Type | Chassis, Panel |
|---|
| Operating Temperature | -40°C ~ 130°C |
|---|
| Material - Insulation | Thermoplastic |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
We can supply Eaton part# TB100-09. Use the request quote form to request TB100-09 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TB100-09. The price and lead time for TB100-09 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TB100-09. We look forward to doing business with you.
