Technical Specifications of 1505-3/4ST
| Datasheet |  1505-3/4ST datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminal Blocks - Barrier Blocks |
|---|
| Manufacturer | Curtis Industries |
|---|
| Series | 1500 |
|---|
| Packaging | Bulk |
|---|
| Terminal Block Type | Barrier Block |
|---|
| Number of Circuits | 5 |
|---|
| Number of Wire Entries | 10 |
|---|
| Pitch | 0.375" (9.53mm) |
|---|
| Number of Rows | 2 |
|---|
| Current Rating | 20A |
|---|
| Voltage Rating | - |
|---|
| Wire Gauge | 12 AWG |
|---|
| Top Termination | Screws with Solder Lugs, Single |
|---|
| Bottom Termination | Closed |
|---|
| Barrier Type | 2 Wall (Dual) |
|---|
| Features | Flange |
|---|
| Color | - |
|---|
| Terminal Screw Material | - |
|---|
| Terminal Screw Finish | Tin |
|---|
| Mounting Type | Chassis, Panel |
|---|
| Operating Temperature | 110°C |
|---|
| Material - Insulation | Polyphenylene Oxide (PPO) |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
We can supply Curtis Industries part# 1505-3/4ST. Use the request quote form to request 1505-3/4ST pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 1505-3/4ST. The price and lead time for 1505-3/4ST depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 1505-3/4ST. We look forward to doing business with you.
