1922705
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1922705 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | 9 Position Terminal Block Plug, Female Sockets 0.400" (10.16mm) 90° Panel Mount |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1922705 Price |  |
Technical Specifications of 1922705
| Category | Connectors, Interconnects |
|---|---|
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Phoenix Contact |
| Series | COMBICON PCU |
| Packaging | Bulk |
| Type | Plug, Female Sockets |
| Number of Positions | 9 |
| Positions Per Level | 9 |
| Number of Levels | 1 |
| Pitch | 0.400" (10.16mm) |
| Header Orientation | - |
| Plug Wire Entry | 90° |
| Termination Style | Screw - Clamping Yoke (Tension Sleeve) |
| Mounting Type | Panel Mount |
| Current - IEC | 41A |
| Voltage - IEC | 1000V |
| Current - UL | 50A |
| Voltage - UL | 600V |
| Wire Gauge or Range - AWG | 8-20 AWG |
| Wire Gauge or Range - mm2 | 0.5-10mm2 |
| Color | Green |
| Operating Temperature | - |
| Contact Mating Finish | Silver |
| Features | Mounting Flange |
