EM221506H
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | EM221506H |
|---|---|
| Manufacturer | Eaton |
| Description | 6 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.197" (5.00mm) 90°, Right Angle Through Hole |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| EM221506H Price |  |
Technical Specifications of EM221506H
| Datasheet |  EM221506H datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Eaton |
| Series | Euro-Mag EM2215 |
| Packaging | Bulk |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Number of Positions | 6 |
| Positions Per Level | 6 |
| Number of Levels | 1 |
| Pitch | 0.197" (5.00mm) |
| Header Orientation | 90°, Right Angle |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 16A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm2 | - |
| Color | Green |
| Operating Temperature | -55°C ~ 105°C |
| Contact Mating Finish | Tin |
| Features | Mating Flange |
