1090280000
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1090280000 |
|---|---|
| Manufacturer | Weidmuller |
| Description | 8 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.300" (7.62mm) 90°, Right Angle Through Hole |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1090280000 Price |  |
Technical Specifications of 1090280000
| Category | Connectors, Interconnects |
|---|---|
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Weidmuller |
| Series | Omnimate SV |
| Packaging | Bulk |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Number of Positions | 8 |
| Positions Per Level | 8 (4 Power + 4 Signal) |
| Number of Levels | Hybrid |
| Pitch | 0.300" (7.62mm) |
| Header Orientation | 90°, Right Angle |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current - IEC | 41A |
| Voltage - IEC | 1000V |
| Current - UL | 33A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm2 | - |
| Color | Black |
| Operating Temperature | -50°C ~ 130°C |
| Contact Mating Finish | Tin |
| Features | - |
