1157290000
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1157290000 |
|---|---|
| Manufacturer | Weidmuller |
| Description | 13 Position Terminal Block Plug, Female Sockets 0.300" (7.62mm) 180° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1157290000 Price |  |
Technical Specifications of 1157290000
| Category | Connectors, Interconnects |
|---|---|
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Weidmuller |
| Series | Omnimate BV |
| Packaging | Bulk |
| Type | Plug, Female Sockets |
| Number of Positions | 13 |
| Positions Per Level | 13 (5 Power + 8 Signal) |
| Number of Levels | Hybrid |
| Pitch | 0.300" (7.62mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 38A |
| Voltage - IEC | 1000V |
| Current - UL | 33A |
| Voltage - UL | 600V |
| Wire Gauge or Range - AWG | 8-24 AWG |
| Wire Gauge or Range - mm2 | 0.5-10mm2 |
| Color | Black |
| Operating Temperature | -50°C ~ 125°C |
| Contact Mating Finish | Tin |
| Features | Latch Lock |
